700Um, Soft Plastics And Very Soft Materials

Barcol 935 – Coatings (min 700m), Soft plastics and Very soft materials

Features
Portable. Easy to use. Can be used in any position and in any space that will allow for an operators hand.

Hardness is instantly indicated on the dial, which is divided into 100 graduations.

Best suited for testing homogeneous materials. Materials of granular, fibrous or coarse structure will produce a wide variation in hardness readings because of the small diameter of the indenter point. For accurate readings, materials should be of at least 700m thick, and large enough for a minimum distance of 3mm in any direction from the indenter point to the edge of the specimen. The test area should be smooth and free from mechanical damage.

The Barcol is used by simply exerting light pressure against the instrument to drive the spring loaded indenter point into the material. The indenter point must be perpendicular to the surface being tested.

Conversion curves are not available for the 935, because physical characteristics of very soft materials are such that uniform correlation between different hardness measuring systems cannot be established.

Supplied with – Two spare indenter points, test disc(s), adjusting wrench & carry case.

Specifications
Range: 50-110HRR
Weight: 500g
